Excavator
Used HYUNDAI R75VS
As-IsLX-R75VS
$13,500 – $102,000indicative range for this machine class
- Year
- Not recorded
- Hours
- Not recorded
- Condition grade
- Not graded yet
- Location
- Sourced to order
- Availability
- Sourced to order after confirmation
- Warranty
- Ask us
Year, hours and grade appear only where we have verified them. See what every machine is checked against · Delivery standards
Request a quote
Get a personalized quote within 1 business day.
Specifications
| Bucket | Backhoe |
|---|---|
| Tonnage (tons) | 7 |
| Total machine operating weight (kg) | 6800 |
| Bucket capacity (m³) | 0.32 |
| boom length (mm) | 3700 |
| Stick length (mm) | 1670 |
| Rotational speed (rpm) | 12.2 |
| Walking speed (km/h) | 4.7 / 2.9 |
| Climbing ability (%) | 58 |
| Engine Model | Yanmar 4TNV98-z |
| Rated power (kW/rpm) | 44.4 / 2100 |
| Maximum torque (Nm) | 24.5/1575 |
| Displacement (L) | 3.319 |
| Number of cylinders | 4 |
| Cylinder bore x stroke (mm) | 98×110 |
| Cooling method | Water cooling |
| Work format | 4-cylinder, 4-stroke, water-cooled, direct-injection engine |
| Main pump type | Two variable displacement piston pumps |
| Rotary hydraulic motor type | Axial piston motor with automatic braking |
| Type of walking hydraulic motor | Dual-speed axial piston motor with brake valve and parking brake |
| Main pump maximum flow rate (l/min) | 2×75.6 (2×20) |
| Boom cylinder – Number x Cylinder diameter x Stroke (mm) | 115x70x980 |
| boom cylinder – number x cylinder diameter x stroke (mm) | 95x60x860 |
| Bucket cylinders – Number x Cylinder diameter x Stroke (mm) | 90x55x665 |
| Fuel tank (L) | 140 |
| Hydraulic oil tank (L) | 75 |
| Hydraulic system (L) | 130 |
| Engine oil change volume (L) | 12 |
| Coolant (L) | 11 |
| Total transport length (mm) | 6080 |
| Total width of transport (mm) | 2260 |
| Total transport height (mm) | 2690 |
| Overall cab height (mm) | 2650 |
| Upper vehicle width (mm) | 2250 |
| Track plate width (mm) | 450/600 |
| Counterweight ground clearance (mm) | 755 |
| Minimum turning radius of the front working device (mm) | 1750 |
| Rear end turning radius (mm) | 1750 |
| Number of support rollers (on one side) | 5 |
| Number of track rollers (one side) | 1 |
| Number of track plates (one side) | 38 |
| Maximum excavation radius (mm) | 6330 |
| Maximum excavation radius at the stopping face (mm) | 6190 |
| Maximum digging depth (mm) | 4150 |
| Maximum digging height (mm) | 7260 |
| Maximum unloading height (mm) | 5170 |
| Maximum vertical excavation depth (mm) | 3200 |
| Maximum effective digging depth (mm) | 3810 |
| bulldozer blade width x height (mm) | 2200×460 |
| Bulldozer blade lifting or pushing depth (mm) | 400/280 |
Description
The Hyundai R75VS excavator is equipped with a Tier 3 engine, delivering outstanding quality with higher reliability and durability. It offers enhanced operator comfort and improved work efficiency, while achieving lower emissions, reduced fuel consumption, and minimized noise levels.
