Excavator
Used CAT 330
As-IsLX-330
$13,500 – $102,000indicative range for this machine class
- Year
- Not recorded
- Hours
- Not recorded
- Condition grade
- Not graded yet
- Location
- Sourced to order
- Availability
- Sourced to order after confirmation
- Warranty
- Ask us
Year, hours and grade appear only where we have verified them. See what every machine is checked against · Delivery standards
Request a quote
Get a personalized quote within 1 business day.
Specifications
| Maximum digging depth | 7370 mm |
|---|---|
| Working weight | 32900 kg |
| Bucket Capacity | 2.0m³ |
| Tail swing radius | 3130 mm |
| Transport width | 3340 mm |
| Transport Height – Top of Cab | 3060 mm |
| Transport length | 10450mm |
| Weight height above the ground | 1120 mm |
| Ground clearance | 480 mm |
| Track length | 4860 mm |
| Length of the heavy-duty wheel center | 3990 mm |
| Track gauge | 2740 mm |
| Maximum ground extension distance | 10680mm |
| Maximum loading height | 6510 mm |
| Minimum loading height | 2170 mm |
| Bucket Digging Force – ISO | 197 kN |
| Stick Digging Force – ISO | 147 kN |
| Net power of the engine-ISO 9249 | 223.7 kW |
| Engine model | Cat 7.1 |
| Engine power-ISO 14396 | 225 kW |
| Bore diameter | 105 mm |
| stroke | 135 mm |
| Displacement | 7.01 L |
| Rotating speed | 11.6 r/n |
| Maximum torque | 111 kN-m |
| Fuel tank capacity | 474 L |
| Cooling system | 25 L |
| Engine oil | 25 L |
| Rotary drive-each | 11.5 L |
| Final drive-gear each | 1.2 L |
| Hydraulic system – oil tank included | 310 L |
| Hydraulic oil tank | 147 L |
Description
The CAT®333 Tier 4 is equipped with a C7.1 twin-turbo engine, delivering a powerful 225 kW of proven performance. With a wider chassis, larger bucket, and increased digging force, it significantly enhances operational efficiency. The reliable exhaust aftertreatment system is maintenance-free throughout its service life and requires no dedicated downtime for regeneration, maximizing working time and ensuring smooth, productive operations.
