Excavator
Used HYUNDAI R495LVS
As-IsLX-R495LVS
$13,500 – $102,000indicative range for this machine class
- Year
- Not recorded
- Hours
- Not recorded
- Condition grade
- Not graded yet
- Location
- Sourced to order
- Availability
- Sourced to order after confirmation
- Warranty
- Ask us
Year, hours and grade appear only where we have verified them. See what every machine is checked against · Delivery standards
Request a quote
Get a personalized quote within 1 business day.
Specifications
| Equipment Model | R495LVS |
|---|---|
| Model Abbreviation | 495 |
| tonnage range | Large excavator (30-50 tons) |
| walking style | tracked |
| Applications | mining type |
| Power type | fuel |
| model | QSM11 |
| Type | 6-cylinder, 4-stroke, water-cooled, inline direct-injection turbocharged air-to-air intercooled engine |
| Rated power (kW) | 263 |
| Rated speed (r/min) | 1900 |
| Maximum torque (N·m) | 170.8 kgf.m |
| Total displacement (L) | 10.8 |
| Number of cylinders | 6 |
| Cylinder bore × stroke (mm) | 125×147.1 |
| Engine Brand | Cummins |
| Working weight (kg) | 45875 |
| Bucket capacity (m³) | 2.5 |
| Walking speed (high/low) (km/h) | 5.0/3.1 |
| Rotational speed (rpm) | 8.5 |
| Climbing ability (%) | 70 |
| Length × Width × Height (in transport condition) (mm) | 11710×3340×3810 |
| Overall cab height (mm) | 3190 |
| Counterweight ground clearance (mm) | 1275 |
| Minimum turning radius (front end device) (mm) | 4526 |
| Rear end turning radius (mm) | 3780 |
| Maximum excavation radius (mm) | 11057 |
| Maximum excavation radius at the stopping face (mm) | 10839 |
| Maximum excavation depth (mm) | 6907 |
| Maximum digging height (mm) | 10363 |
| Maximum unloading height (mm) | 6983 |
| Maximum vertical excavation depth (mm) | 5419 |
| Fuel tank (L) | 620 |
| Hydraulic oil tank (L) | 262 |
| Engine oil change volume (L) | 38 |
| Coolant (L) | 50 |
| Working hydraulic circuit (MPa) | 33 |
| Travel hydraulic circuit (MPa) | 36 |
| Rotary hydraulic circuit (MPa) | 30 |
| Maximum pressure of the pilot system (MPa) | 4 |
| Boom cylinder – cylinder bore × stroke (mm) | 2-ø170×ø115×1570 |
| boom cylinder – cylinder diameter × stroke (mm) | 1-ø190×ø130×1820 |
| Bucket cylinder – cylinder diameter × stroke (mm) | 1-ø170×ø115×1370 |
Description
This unit is available now. Key specifications: Equipment Model: R495LVS; Model Abbreviation: 495; tonnage range: Large excavator (30-50 tons); walking style: tracked.
