Scissor Lift
Used Dingli JCPT1012 Scissor lift
As-IsLX-JCPT1012
$3,000 – $6,500indicative range for this machine class
- Year
- Not recorded
- Hours
- Not recorded
- Condition grade
- Not graded yet
- Location
- Sourced to order
- Availability
- Sourced to order after confirmation
- Warranty
- Ask us
Year, hours and grade appear only where we have verified them. See what every machine is checked against · Delivery standards
Request a quote
Get a personalized quote within 1 business day.
Specifications
| Model | JCPT1012DC |
|---|---|
| Maximum working height A | 10.00m |
| Maximum platform height B | 8.00m |
| Overall length C | 2.48m |
| Overall width D | 1.15m |
| Overall height (fence not folded) | 2.36m |
| Overall height (fence folded) E | 1.83m |
| Work platform size (length x width F) | 2.27mX1.12m |
| Platform extension dimension G | 0.90m |
| Minimum ground clearance (in collapsed state) | 0.10m |
| Minimum ground clearance (raised position) | 0.019m |
| Wheelbase | 1.87m |
| Safety working load | 450kg |
| Extended platform safe working load | 113kg |
| Maximum number of workers | 2 |
| Minimum turning radius (inside wheel/ outside wheel) | 0/2.20m |
| Machine travel speed (collapsible state) | 4km/h |
| Machine travel speed (lift state) | 0.8km/h |
| Ascent/Descent rate | 36/33sec |
| Maximum climbing ability | 25% |
| Maximum allowable working angle (European standard/US standard) | 1.5°/3°, 2°/3° |
| Tire | 381X127mm |
| Drive motor | 24V/1.5kW |
| Lifting motor | 24V/3.3kW |
| Battery | 4X6V/225Ah |
| Charger | 24V/30A |
| Gross weight of the machine (European standard) | 2655kg |
| Gross weight of the machine (US standard) | 2255kg |
Description
JCPT1012DC electric scissor lift for high-altitude work is battery-driven, low noise, no pollution, and suitable for various working environments.
